Photos lift out of their thumbnails, swipe between, zoom, and land back where they came from.

Mediamotion@base-ui/react@number-flow/react

01Preview

14 Harbour Lane

4 bed · 3 bath · 2,480 sq ft

6 photos

02Install

Copy the source into your project. It becomes yours: no package to update, no wrapper between you and the markup. It needs:

npm install motion @base-ui/react @number-flow/react

03Usage

import { Lightbox, LightboxTrigger } from "@/components/ui/lightbox";

<Lightbox images={photos}>
  <div className="grid grid-cols-3 gap-1.5">
    {photos.map((photo, i) => (
      <LightboxTrigger key={photo.src} index={i} className="aspect-square" />
    ))}
  </div>
</Lightbox>

// photos: { src, thumb?, alt, width, height, caption? }[]

04Source

"use client";
import { Dialog } from "@base-ui/react/dialog";
import NumberFlow from "@number-flow/react";
import { animate, motion, useMotionValue, useReducedMotion, useTransform, type AnimationPlaybackControls } from "motion/react";
import { createContext, use, useCallback, useEffect, useLayoutEffect, useRef, useState } from "react";
import { cn } from "@/lib/cn";
import { ChevronLeft, ChevronRight, X, ZoomIn, ZoomOut } from "@/lib/icons";
import { ease, spring } from "@/lib/motion";
import { useControllableState } from "@/lib/use-controllable-state";
import { useZoomPan } from "@/components/ui/zoom-pan-image";

export type LightboxImage = {
  src: string;
  alt: string;
  /** Intrinsic size, so the image is fitted and the flight is planned before it loads. */
  width: number;
  height: number;
  /** A smaller file already on the page. Shown instantly while `src` loads. Defaults to `src`. */
  thumb?: string;
  caption?: React.ReactNode;
};

type Phase = "closed" | "opening" | "open" | "closing";
type Rect = { left: number; top: number; width: number; height: number; radius: number };

type Ctx = {
  images: LightboxImage[];
  index: number;
  phase: Phase;
  openAt: (i: number, from: HTMLElement) => void;
  register: (i: number, el: HTMLElement | null) => void;
};
const LightboxContext = createContext<Ctx | null>(null);
const useLightbox = () => {
  const ctx = use(LightboxContext);
  if (!ctx) throw new Error("Lightbox parts must be inside <Lightbox>");
  return ctx;
};

const clamp = (v: number, lo: number, hi: number) => Math.min(hi, Math.max(lo, v));
const band = (over: number, size: number) => (over * size * 0.55) / (size + 0.55 * over);

function rectOf(el: HTMLElement): Rect {
  const r = el.getBoundingClientRect();
  return { left: r.left, top: r.top, width: r.width, height: r.height, radius: parseFloat(getComputedStyle(el).borderTopLeftRadius) || 0 };
}

export type LightboxProps = {
  images: LightboxImage[];
  index?: number;
  defaultIndex?: number;
  onIndexChange?: (index: number) => void;
  open?: boolean;
  defaultOpen?: boolean;
  onOpenChange?: (open: boolean) => void;
  /**
   * Render the viewer inside this element instead of over the whole page. The element needs
   * position: relative and overflow: hidden; page scroll isn't locked.
   */
  container?: HTMLElement | null;
  /**
   * Finds the on-page image for an index when the thumbnails aren't LightboxTriggers (a gallery
   * grid, say), so the viewer can still fly out of and back into them.
   */
  getThumbnail?: (index: number) => HTMLElement | null;
  /** Accessible label of the viewer. Defaults to "Photo 3 of 8". */
  getLabel?: (index: number, total: number) => string;
  children: React.ReactNode;
};

export function Lightbox({
  images,
  index: indexProp,
  defaultIndex = 0,
  onIndexChange,
  open: openProp,
  defaultOpen = false,
  onOpenChange,
  container,
  getThumbnail,
  getLabel = (i, n) => `Photo ${i + 1} of ${n}`,
  children,
}: LightboxProps) {
  const [index, setIndex] = useControllableState({ value: indexProp, defaultValue: defaultIndex, onChange: onIndexChange });
  const [open, setOpen] = useControllableState({ value: openProp, defaultValue: defaultOpen, onChange: onOpenChange });
  const thumbs = useRef(new Map<number, HTMLElement>());
  // The phase runs a step behind `open`: the viewer stays mounted while it flies back.
  const [phase, setPhase] = useState<Phase>(open ? "open" : "closed");
  const [from, setFrom] = useState<Rect | null>(null);
  const [instant, setInstant] = useState(false);
  const [prevOpen, setPrevOpen] = useState(open);

  // An open or close requested from outside (controlled) still flies.
  if (prevOpen !== open) {
    setPrevOpen(open);
    if (open && (phase === "closed" || phase === "closing")) {
      setFrom(null);
      setPhase("opening");
    }
    if (!open && (phase === "open" || phase === "opening")) setPhase("closing");
  }

  const register = useCallback((i: number, el: HTMLElement | null) => {
    if (el) thumbs.current.set(i, el);
    else thumbs.current.delete(i);
  }, []);

  const openAt = useCallback(
    (i: number, el: HTMLElement) => {
      setFrom(rectOf(el));
      setInstant(false);
      setIndex(i);
      setPhase("opening");
      setOpen(true);
    },
    [setIndex, setOpen],
  );

  const requestClose = useCallback(
    (quick = false) => {
      setInstant(quick);
      setPhase((p) => (p === "closed" ? p : "closing"));
      setOpen(false);
    },
    [setOpen],
  );

  const mounted = phase !== "closed";

  return (
    <LightboxContext value={{ images, index, phase, openAt, register }}>
      <Dialog.Root
        open={mounted}
        modal={container ? "trap-focus" : true}
        onOpenChange={(next) => {
          if (!next) requestClose();
        }}
      >
        {children}
        {mounted && (
          <Dialog.Portal container={container}>
            <Viewer
              images={images}
              index={index}
              setIndex={setIndex}
              phase={phase}
              from={from}
              instant={instant}
              contained={container != null}
              label={getLabel(index, images.length)}
              thumbFor={(i) => thumbs.current.get(i) ?? getThumbnail?.(i) ?? null}
              onOpened={() => setPhase((p) => (p === "opening" ? "open" : p))}
              onClosed={() => setPhase((p) => (p === "closing" ? "closed" : p))}
              requestClose={requestClose}
            />
          </Dialog.Portal>
        )}
      </Dialog.Root>
    </LightboxContext>
  );
}

export type LightboxTriggerProps = Omit<React.ComponentProps<"button">, "children"> & {
  index: number;
  /** Classes for the thumbnail image. */
  imgClassName?: string;
};

/** A thumbnail that opens the viewer. The image flies out of it, and back into it on close. */
export function LightboxTrigger({ index, className, imgClassName, onClick, ref, ...rest }: LightboxTriggerProps) {
  const { images, index: current, phase, openAt, register } = useLightbox();
  const image = images[index];
  // While its image is up in the viewer, the thumbnail's slot stays empty: that's where it will land.
  const lifted = phase !== "closed" && current === index;
  return (
    <button
      type="button"
      aria-label={`View ${image.alt}`}
      aria-haspopup="dialog"
      data-lifted={lifted || undefined}
      ref={(el) => {
        register(index, el);
        if (typeof ref === "function") return ref(el);
        if (ref) ref.current = el;
      }}
      onClick={(e) => {
        onClick?.(e);
        if (!e.defaultPrevented) openAt(index, e.currentTarget);
      }}
      className={cn(
        "group/thumb relative block overflow-hidden rounded-lg bg-hover",
        "outline-none focus-visible:outline-solid focus-visible:outline-1 focus-visible:outline-offset-2 focus-visible:outline-fg-3",
        "transition-[scale] duration-150 ease-out active:scale-[0.97] active:duration-75",
        "after:absolute after:inset-0 after:rounded-[inherit] after:bg-page/0 after:transition-colors after:duration-150 hover:after:bg-page/15",
        className,
      )}
      {...rest}
    >
      {/* eslint-disable-next-line @next/next/no-img-element */}
      <img
        src={image.thumb ?? image.src}
        alt=""
        draggable={false}
        decoding="async"
        className={cn("size-full object-cover group-data-lifted/thumb:opacity-0", imgClassName)}
      />
    </button>
  );
}

type ViewerProps = {
  images: LightboxImage[];
  index: number;
  setIndex: (i: number) => void;
  phase: Phase;
  from: Rect | null;
  instant: boolean;
  contained: boolean;
  label: string;
  thumbFor: (i: number) => HTMLElement | null;
  onOpened: () => void;
  onClosed: () => void;
  requestClose: (quick?: boolean) => void;
};

const GAP = 24;

function Viewer({ images, index, setIndex, phase, from, instant, contained, label, thumbFor, onOpened, onClosed, requestClose }: ViewerProps) {
  const reduce = !!useReducedMotion();
  const image = images[index];
  const count = images.length;
  const live = phase === "open";
  // Lets a close drop a swipe that is still under the finger.
  const cancelSwipe = useRef<() => void>(() => {});
  const {
    viewportRef,
    contentRef,
    x,
    y,
    scale,
    zoomed,
    reset,
    toggle,
    onKeyDown: zoomKeys,
  } = useZoomPan({ max: 4, doubleTapScale: 2.5, wheel: "modifier", disabled: !live });
  const track = useMotionValue(0);
  const veil = useMotionValue(0);
  // How far the image is cropped toward its thumbnail: insets in the content's own pixels, and a radius.
  const crop = useMotionValue({ t: 0, r: 0, b: 0, l: 0, radius: 0 });
  const clipPath = useTransform(() => {
    const c = crop.get();
    return c.t || c.r || c.b || c.l || c.radius ? `inset(${c.t}px ${c.r}px ${c.b}px ${c.l}px round ${c.radius}px)` : "none";
  });
  const chrome = useTransform(() => clamp((veil.get() - 0.6) / 0.4, 0, 1));
  const flight = useRef<AnimationPlaybackControls | null>(null);
  const [settledIndex, setSettledIndex] = useState(index);
  // Where a pointer navigation is heading: the counter and caption change as the move starts, not after it.
  const [heading, setHeading] = useState<{ from: number; to: number } | null>(null);
  const shown = heading && heading.from === index ? heading.to : index;
  const shownImage = images[shown];

  // Plan a flight between the fitted image and a thumbnail rect (client px). Returns the values
  // that make the content sit exactly over the thumbnail, cropped like object-fit: cover.
  const plan = useCallback(
    (target: Rect) => {
      const v = viewportRef.current;
      const c = contentRef.current;
      if (!v || !c) return null;
      const vr = v.getBoundingClientRect();
      const R = { left: c.offsetLeft, top: c.offsetTop, w: c.offsetWidth, h: c.offsetHeight };
      if (!R.w || !R.h) return null;
      const T = { left: target.left - vr.left, top: target.top - vr.top, w: target.width, h: target.height };
      const k = Math.max(T.w / R.w, T.h / R.h);
      const cropX = (R.w - T.w / k) / 2;
      const cropY = (R.h - T.h / k) / 2;
      return {
        s: k,
        // Content is scaled from its top-left; place it so the visible (cropped) window lands on T.
        x: T.left - R.left - cropX * k,
        y: T.top - R.top - cropY * k,
        crop: { t: cropY, r: cropX, b: cropY, l: cropX, radius: target.radius / k },
        visible: T.left + T.w > 0 && T.top + T.h > 0 && T.left < vr.width && T.top < vr.height,
      };
    },
    [viewportRef, contentRef],
  );

  // Drive x, y, scale, crop and the veil from one progress value, so they can never drift apart.
  const fly = useCallback(
    (to: { s: number; x: number; y: number; crop: { t: number; r: number; b: number; l: number; radius: number }; veil: number }, transition: object, done: () => void) => {
      flight.current?.stop();
      const f = { s: scale.get(), x: x.get(), y: y.get(), crop: crop.get(), veil: veil.get() };
      const lerp = (a: number, b: number, t: number) => a + (b - a) * t;
      flight.current = animate(0, 1, {
        ...transition,
        onUpdate: (t) => {
          scale.set(lerp(f.s, to.s, t));
          x.set(lerp(f.x, to.x, t));
          y.set(lerp(f.y, to.y, t));
          veil.set(clamp(lerp(f.veil, to.veil, t), 0, 1));
          crop.set({
            t: Math.max(0, lerp(f.crop.t, to.crop.t, t)),
            r: Math.max(0, lerp(f.crop.r, to.crop.r, t)),
            b: Math.max(0, lerp(f.crop.b, to.crop.b, t)),
            l: Math.max(0, lerp(f.crop.l, to.crop.l, t)),
            radius: Math.max(0, lerp(f.crop.radius, to.crop.radius, t)),
          });
        },
        onComplete: done,
      });
    },
    [scale, x, y, crop, veil],
  );

  const none = { t: 0, r: 0, b: 0, l: 0, radius: 0 };

  // Opening: start exactly over the thumbnail, before the first paint, then fly out.
  useLayoutEffect(() => {
    if (phase !== "opening") return;
    const el = from ? null : thumbFor(index);
    const rect = from ?? (el ? rectOf(el) : null);
    const p = rect && !reduce ? plan(rect) : null;
    if (!p) {
      scale.set(reduce ? 1 : 0.96);
      veil.set(0);
      fly({ s: 1, x: 0, y: 0, crop: none, veil: 1 }, { duration: reduce ? 0.15 : 0.22, ease: ease.out }, onOpened);
      return;
    }
    scale.set(p.s);
    x.set(p.x);
    y.set(p.y);
    crop.set(p.crop);
    veil.set(0);
    fly({ s: 1, x: 0, y: 0, crop: none, veil: 1 }, spring.soft, onOpened);
    // Runs once per opening; the values it reads are fixed for that flight.
    // eslint-disable-next-line react-hooks/exhaustive-deps
  }, [phase]);

  // Closing: back into the thumbnail of whichever image is showing now, from wherever it is.
  useLayoutEffect(() => {
    if (phase !== "closing") return;
    cancelSwipe.current();
    track.set(0);
    const el = thumbFor(index);
    const p = el && !reduce && !instant ? plan(rectOf(el)) : null;
    if (!p || !p.visible) {
      // The thumbnail is off screen (or motion is reduced): fade where it stands instead.
      fly({ s: reduce || instant ? scale.get() : scale.get() * 0.96, x: x.get(), y: y.get(), crop: crop.get(), veil: 0 }, { duration: instant ? 0 : reduce ? 0.12 : 0.16, ease: ease.in }, onClosed);
      return;
    }
    fly({ s: p.s, x: p.x, y: p.y, crop: p.crop, veil: 0 }, spring.snappy, onClosed);
    // eslint-disable-next-line react-hooks/exhaustive-deps
  }, [phase]);

  useEffect(() => () => flight.current?.stop(), []);

  // A new image starts unzoomed; the strip snaps back under it in the same frame.
  if (settledIndex !== index) setSettledIndex(index);
  useLayoutEffect(() => {
    if (phase !== "open") return;
    track.set(0);
    reset({ instant: true });
    // eslint-disable-next-line react-hooks/exhaustive-deps
  }, [settledIndex]);

  const go = useCallback(
    (dir: 1 | -1, how: "pointer" | "key") => {
      const next = index + dir;
      if (next < 0 || next >= count || phase !== "open") return;
      const w = viewportRef.current?.clientWidth ?? 0;
      if (how === "key" || reduce || !w) return setIndex(next);
      flight.current?.stop();
      setHeading({ from: index, to: next });
      flight.current = animate(track, -dir * (w + GAP), { ...spring.snappy, onComplete: () => setIndex(next) });
    },
    [index, count, phase, reduce, setIndex, track, viewportRef],
  );

  // Single-pointer drags at rest: sideways to move between images, down (or up) to dismiss.
  useEffect(() => {
    const el = viewportRef.current;
    if (!el || phase !== "open") return;
    let start: { x: number; y: number; id: number } | null = null;
    let axis: "x" | "y" | null = null;
    let active = 0;
    let startedOn: EventTarget | null = null;

    const cancel = () => {
      if (!start) return;
      start = null;
      axis = null;
      animate(track, 0, spring.snappy);
      animate(y, 0, spring.snappy);
      animate(scale, 1, spring.snappy);
      animate(veil, 1, { duration: 0.2 });
    };
    cancelSwipe.current = cancel;

    const down = (e: PointerEvent) => {
      active++;
      if (active > 1 || scale.get() > 1.001 || (e.pointerType === "mouse" && e.button !== 0)) {
        if (start) cancel();
        return;
      }
      if ((e.target as HTMLElement).closest("button")) return;
      start = { x: e.clientX, y: e.clientY, id: e.pointerId };
      startedOn = e.target;
      axis = null;
    };
    const move = (e: PointerEvent) => {
      if (!start || e.pointerId !== start.id) return;
      const dx = e.clientX - start.x;
      const dy = e.clientY - start.y;
      if (!axis) {
        if (Math.hypot(dx, dy) < 6) return;
        axis = Math.abs(dx) > Math.abs(dy) ? "x" : "y";
        el.setPointerCapture(e.pointerId);
        flight.current?.stop();
      }
      const w = el.clientWidth;
      const h = el.clientHeight;
      if (axis === "x") {
        const atEdge = (dx > 0 && index === 0) || (dx < 0 && index === count - 1);
        track.set(atEdge ? Math.sign(dx) * band(Math.abs(dx), w) : dx);
      } else {
        // The image follows the finger 1:1 and shrinks a little; the veil thins as it goes.
        const d = Math.abs(dy);
        y.set(dy);
        scale.set(1 - Math.min(d / h, 1) * 0.25);
        veil.set(1 - Math.min(d / (h * 0.6), 1));
      }
    };
    const up = (e: PointerEvent) => {
      active = Math.max(0, active - 1);
      if (!start || e.pointerId !== start.id) return;
      const s = start;
      start = null;
      const dx = e.clientX - s.x;
      const dy = e.clientY - s.y;
      if (!axis) {
        // A plain click on the dark around the image closes it.
        if (e.type === "pointerup" && startedOn === el && !contentRef.current?.contains(e.target as Node)) requestClose();
        return;
      }
      if (axis === "x") {
        const v = track.getVelocity();
        const w = el.clientWidth;
        const dir = dx < 0 ? 1 : -1;
        const next = index + dir;
        if ((Math.abs(dx) > w * 0.2 || Math.abs(v) > 500) && Math.sign(v || dx) === -dir && next >= 0 && next < count) {
          setHeading({ from: index, to: next });
          flight.current = animate(track, -dir * (w + GAP), { ...spring.snappy, velocity: v, onComplete: () => setIndex(next) });
        } else animate(track, 0, { ...spring.snappy, velocity: v });
      } else {
        const v = y.getVelocity();
        if (Math.abs(dy) > 110 || Math.abs(v) > 700) requestClose();
        else {
          animate(y, 0, { ...spring.snappy, velocity: v });
          animate(scale, 1, spring.snappy);
          animate(veil, 1, { duration: 0.2, ease: ease.out });
        }
      }
      axis = null;
    };
    el.addEventListener("pointerdown", down);
    el.addEventListener("pointermove", move);
    el.addEventListener("pointerup", up);
    el.addEventListener("pointercancel", up);
    return () => {
      el.removeEventListener("pointerdown", down);
      el.removeEventListener("pointermove", move);
      el.removeEventListener("pointerup", up);
      el.removeEventListener("pointercancel", up);
      cancelSwipe.current = () => {};
    };
  }, [phase, index, count, viewportRef, contentRef, track, y, scale, veil, setIndex, requestClose]);

  const slides = [index - 1, index, index + 1].filter((i) => i >= 0 && i < count);
  const chromeHidden = phase !== "open";

  return (
    <>
      <Dialog.Backdrop
        render={<motion.div style={{ opacity: veil }} />}
        className={cn(contained ? "absolute" : "fixed", "inset-0 z-(--z-overlay) bg-page")}
      />
      <Dialog.Popup
        finalFocus={() => thumbFor(index) ?? true}
        className={cn(contained ? "absolute" : "fixed", "inset-0 z-(--z-dialog) outline-none")}
        onKeyDown={(e) => {
          zoomKeys(e);
          if (e.defaultPrevented) return;
          if (e.key === "ArrowRight") go(1, "key");
          else if (e.key === "ArrowLeft") go(-1, "key");
          else return;
          e.preventDefault();
        }}
      >
        <div
          ref={viewportRef}
          data-zoomed={zoomed || undefined}
          className="absolute inset-0 touch-none select-none overflow-hidden [container-type:size] [--lb-x:24px] sm:[--lb-x:128px]"
        >
          <motion.div className="absolute inset-0" style={{ x: track }}>
            {slides.map((i) => {
              const img = images[i];
              const ratio = img.width / img.height;
              const isActive = i === index;
              return (
                <div
                  key={i}
                  aria-hidden={!isActive || undefined}
                  className="absolute inset-0"
                  style={{ transform: `translateX(calc(${(i - index) * 100}% + ${(i - index) * GAP}px))` }}
                >
                  <motion.div
                    ref={isActive ? contentRef : undefined}
                    // Fitted inside the space the chrome leaves, at the image's own ratio.
                    className={cn(
                      "absolute inset-x-3 bottom-[76px] top-14 m-auto sm:inset-x-16",
                      isActive && live && (zoomed ? "cursor-grab active:cursor-grabbing" : "cursor-zoom-in"),
                    )}
                    style={{
                      width: `min(100cqw - var(--lb-x), (100cqh - 132px) * ${ratio})`,
                      height: `min(100cqh - 132px, (100cqw - var(--lb-x)) / ${ratio})`,
                      ...(isActive ? { x, y, scale, originX: 0, originY: 0, clipPath } : {}),
                    }}
                  >
                    <SlideImage image={img} priority={isActive} />
                  </motion.div>
                </div>
              );
            })}
          </motion.div>
        </div>

        {/* Chrome: fades in once the image has landed, and out the moment it leaves. */}
        <motion.div style={{ opacity: chrome }} className={cn("pointer-events-none absolute inset-0", !chromeHidden && "*:pointer-events-auto")}>
          <div className="absolute inset-x-0 top-0 flex h-14 items-center justify-between gap-3 px-3 sm:px-4">
            <Dialog.Title className="flex h-7 items-center gap-1 rounded-full border border-line-2 bg-raised/80 px-2.5 font-mono text-[11.5px] text-fg-2 shadow-[var(--shadow)] backdrop-blur-sm tabular">
              <span className="sr-only">
                {label}: {image.alt}
              </span>
              <NumberFlow aria-hidden value={shown + 1} animated={!reduce} className="text-fg" />
              <span aria-hidden className="text-fg-3">
                / {count}
              </span>
            </Dialog.Title>
            <div className="flex items-center gap-1">
              <ChromeButton label={zoomed ? "Zoom out" : "Zoom in"} onClick={() => toggle()}>
                {zoomed ? <ZoomOut /> : <ZoomIn />}
              </ChromeButton>
              <Dialog.Close
                aria-label="Close"
                className={chromeButtonClass}
              >
                <X />
              </Dialog.Close>
            </div>
          </div>

          <NavButton side="left" label="Previous photo" disabled={index === 0} onClick={() => go(-1, "pointer")} />
          <NavButton side="right" label="Next photo" disabled={index === count - 1} onClick={() => go(1, "pointer")} />

          <div className="pointer-events-none! absolute inset-x-0 bottom-0 flex h-[76px] items-center justify-center px-14 sm:px-16">
            <p
              key={shown}
              className={cn(
                "line-clamp-2 max-w-[60ch] text-balance text-center text-[12.5px] leading-[18px] text-fg-2 transition-opacity duration-200 starting:opacity-0",
                // Out of the way while zoomed: the photo has the whole frame.
                zoomed && "opacity-0",
              )}
            >
              {shownImage.caption ?? shownImage.alt}
            </p>
          </div>
        </motion.div>
      </Dialog.Popup>
    </>
  );
}

// The thumbnail (already decoded on the page) shows at once; the full file fades in over it.
function SlideImage({ image, priority }: { image: LightboxImage; priority: boolean }) {
  const [loaded, setLoaded] = useState(false);
  return (
    <>
      {image.thumb && (
        // eslint-disable-next-line @next/next/no-img-element
        <img src={image.thumb} alt="" draggable={false} className="pointer-events-none absolute inset-0 size-full object-cover" />
      )}
      {/* eslint-disable-next-line @next/next/no-img-element */}
      <img
        ref={(img) => {
          if (img?.complete && img.naturalWidth) setLoaded(true);
        }}
        src={image.src}
        alt=""
        draggable={false}
        decoding="async"
        fetchPriority={priority ? "high" : undefined}
        onLoad={() => setLoaded(true)}
        className={cn(
          "pointer-events-none absolute inset-0 size-full object-cover transition-opacity duration-300 ease-out",
          loaded || !image.thumb ? "opacity-100" : "opacity-0",
        )}
      />
    </>
  );
}

// Chrome sits on its own small surfaces, so it stays legible over a zoomed photo in either theme.
const chromeButtonClass = cn(
  "relative grid size-8 place-items-center rounded-full border border-line-2 bg-raised/80 text-fg-2 shadow-[var(--shadow)] backdrop-blur-sm",
  "outline-none focus-visible:outline-solid focus-visible:outline-1 focus-visible:outline-offset-2 focus-visible:outline-fg-3",
  "transition-[background-color,color,scale] duration-150 hover:bg-hover hover:text-fg active:scale-[0.92] active:duration-75",
  "before:absolute before:-inset-1.5 before:content-[''] pointer-fine:before:hidden",
);

function ChromeButton({ label, children, ...rest }: React.ComponentProps<"button"> & { label: string }) {
  return (
    <button type="button" aria-label={label} title={label} className={chromeButtonClass} {...rest}>
      {children}
    </button>
  );
}

function NavButton({ side, label, ...rest }: React.ComponentProps<"button"> & { side: "left" | "right"; label: string }) {
  return (
    <button
      type="button"
      aria-label={label}
      title={label}
      className={cn(
        "group/nav absolute bottom-5 grid size-9 place-items-center rounded-full border border-line-2 bg-raised/80 text-fg-2 shadow-[var(--shadow)] backdrop-blur-sm sm:bottom-auto sm:top-1/2 sm:-translate-y-1/2",
        side === "left" ? "left-3 sm:left-4" : "right-3 sm:right-4",
        "outline-none focus-visible:outline-solid focus-visible:outline-1 focus-visible:outline-offset-2 focus-visible:outline-fg-3",
        "transition-[background-color,color,scale,opacity] duration-150 enabled:hover:bg-hover enabled:hover:text-fg enabled:active:scale-[0.92] enabled:active:duration-75",
        "disabled:opacity-0",
        "before:absolute before:-inset-1 before:content-['']",
      )}
      {...rest}
    >
      {side === "left" ? (
        <ChevronLeft className="transition-transform duration-150 ease-out group-enabled/nav:group-hover/nav:-translate-x-px" />
      ) : (
        <ChevronRight className="transition-transform duration-150 ease-out group-enabled/nav:group-hover/nav:translate-x-px" />
      )}
    </button>
  );
}

05Props

Lightbox

PropTypeDefaultDescription
images*LightboxImage[]{ src, alt, width, height, thumb?, caption? }. thumb is the whole image, smaller (not a crop), shown at once while src loads.
index / defaultIndexnumber0The image showing. Controlled or uncontrolled.
onIndexChange(index: number) => voidCalled when the viewer moves to another image.
open / defaultOpenbooleanfalseWhether the viewer is open. Opening from outside still flies from the current image's thumbnail.
onOpenChange(open: boolean) => voidCalled when it opens or starts to close.
containerHTMLElement | nullRender the viewer inside this element (position: relative, overflow: hidden) instead of over the page.
getThumbnail(index: number) => HTMLElement | nullFinds the on-page image for an index when the thumbnails aren't LightboxTriggers (a gallery grid), so it still flies out of and back into them.
getLabel(index: number, total: number) => string"Photo 3 of 8"The viewer's accessible title.

LightboxTrigger

PropTypeDefaultDescription
index*numberWhich image this thumbnail opens. Size it with className; the image covers it.
imgClassNamestringClasses for the thumbnail image.

06Notes

Behavior

  • The photo leaves its thumbnail cropped exactly as the thumbnail shows it, then un-crops to its full shape as it grows; the empty slot stays visible so it's clear where it will return.
  • Closing lands in the thumbnail of whichever photo is showing, not the one that was opened. If that thumbnail is scrolled out of view, the photo fades where it stands instead of flying off screen.
  • Swipe sideways to move (20% of the width or a flick commits; the ends rubber-band). Drag up or down to dismiss: the photo follows 1:1, shrinks up to 25% and the backdrop thins; past 110px or a flick it flies home.
  • Double-click, double-tap, pinch or ⌘-scroll to zoom (the zoom-pan-image hook); swipes and dismiss wait until you're back at fit. A click on the dark around the photo closes.

Motion

  • One progress value drives position, scale, crop, corner radius and backdrop together: out on the soft spring (260/28), home on the snappy spring (520/38), so the pieces can never drift apart.
  • The counter, buttons and caption fade in over the last 40% of the flight and are gone in its first frames on the way back. The counter rolls and the caption changes as a move starts, not after it.
  • Arrow keys switch instantly; buttons and swipes slide on the snappy spring with a 24px gap. Reduced motion replaces the flights with a 150ms fade and makes every switch instant.

Accessibility

  • A Base UI dialog: focus is trapped, the page is inert, Escape closes, and focus returns to the thumbnail of the photo that was showing.
  • The title reads “Photo 3 of 8: <alt>”. Left and right arrows move; + / − / 0 zoom; arrows pan while zoomed.
  • Thumbnails are buttons named “View <alt>” with aria-haspopup; every control in the viewer is a labeled button.
